Our Pharmaceutical Laboratory Scientific Compounding Lines are designed for precise, hygienic processing of pharmaceutical materials in cleanroom environments. Built in compliance with GMP standards, these systems offer high flexibility for handling APIs, polymers, and additives, ensuring consistent product quality. The modular design, combined with robust stainless-steel construction, allows easy cleaning, maintenance, and adaptability for various pharmaceutical compounding applications.
The complete line integrates a Twin-Screw Extruder, Air-Cooling Conveyor, and Strand Pelletizer into a streamlined process solution. The Twin-Screw Extruder ensures homogeneous mixing and controlled melt processing, the Air-Cooling Conveyor provides rapid and uniform cooling to prevent sticking, and the Strand Pelletizer delivers precise, consistent pellet size. Together, these units form an efficient and reliable system for pharmaceutical compounding and pellet production.
Twin Screw Extruder Pharma | 12 mm. | 16 mm. | 20 mm. | 26 mm. | 36 mm. |
|---|---|---|---|---|---|
Available L/D Ratios | 25 to 40 | 32 to 40 | 32 to 40 | 32 to 40 | 40 to 60 |
Screw Speed (RPM) | 0 to 800 | 0 to 800 | 0 to 800 | 0 to 800 | 0 to 900 |
Motor Power (kW) | 2.0 kW | 2.2 kW | 5.5 kW | 15 kW | 65 kW |
Maximum torque at 900 RPM | 2 x 12 Nm | 2 x 18 Nm | 2 x 44 Nm | 2 x 90 Nm | 2 x 278 Nm |
Max barrel temp. (standard) | 300 °C | 400 °C | 400 °C | 400 °C | 400 °C |
Maximum output (LDPE) | 4 kg/hr | 5 kg/hr | 20 kg/hr | 40 kg/hr | 100-150 kg/hr |
